Parameter
A.6 Block parameter MMLog
Parameter Data format
Feature STRUCT
Bit 0: BOOL
•
...
•
Bit 31:
•
BOOL
ReserveIn WORD
Output parameters
Table A- 20 Output parameter MMLog
Parameter Data format
RackF_Act STRUCT
Value:
•
BOOL
ST: BYTE
•
ModF_Act STRUCT
Value:
•
BOOL
ST: BYTE
•
RdErr STRUCT
Value:
•
BOOL
ST: BYTE
•
RdErrStat WORD
StaTmst BYTE
TmstmpAct STRUCT
Value:
•
BOOL
ST: BYTE
•
Sync_Ok BOOL
OflwBuf BOOL
RdAct BOOL
LocalAct STRUCT
Value:
•
BOOL
ST: BYTE
•
OnAct STRUCT
Value:
•
BOOL
ST: BYTE
•
270
Default setting Meaning
– Status of various features
0
•
0
•
0
•
16#00 Reserved
Default setting Meaning
– 1 = Rack Failure
0
•
16#80
•
– 1 = Module Failure
0
•
16#80
•
– 1 = Error read record
0
•
16#80
•
16#00 Status of read record error
0 Status of time stamp functionality
– 1 = Time stamp functionality active
0
•
16#80
•
FALSE 1 = Synchronization ok
FALSE 1 = Buffer overflow
TRUE 1 = Enable read/write record
– 1 = Motor in Local Operation Mode: Local Mode Indicator
1
•
16#80
•
– On Mode is active
1
•
16#80
•
