Parameter Data format
TripTime STRUCT
Value: REAL
•
ST: BYTE
•
MotcolTm STRUCT
Value: REAL
•
ST: BYTE
•
MotVol1 STRUCT
Value: REAL
•
ST: BYTE
•
MotVol2 STRUCT
Value: REAL
•
ST: BYTE
•
MotVol3 STRUCT
Value: REAL
•
ST: BYTE
•
AMOut STRUCT
Value: REAL
•
ST: BYTE
•
AMOutE STRUCT
Value: REAL
•
ST: BYTE
•
AMIn1 STRUCT
Value: REAL
•
ST: BYTE
•
AMIn1E STRUCT
Value: REAL
•
ST: BYTE
•
AMIn2 STRUCT
Value: REAL
•
ST: BYTE
•
AMIn2E STRUCT
Value: REAL
•
ST: BYTE
•
AMIn3 STRUCT
Value: REAL
•
ST: BYTE
•
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Default setting Meaning
– Time Until Tripping [sec]
0.0
•
16#80
•
– Remaining cool down time of the motor in sec
0.0
•
16#80
•
– Motor Voltage UL1 in Volt
0.0
•
16#80
•
– Motor Voltage UL2 in Volt
0.0
•
16#80
•
– Motor Voltage UL3 in Volt
0.0
•
16#80
•
– Analog output
0.0
•
16#80
•
– Analog Output Effective in mA
0.0
•
16#80
•
– Analog input 1
0.0
•
16#80
•
– Analog Input 1 Effective in mA
0.0
•
16#80
•
– Analog input 2
0.0
•
16#80
•
– Analog Input 2 Effective in mA
0.0
•
16#80
•
– Analog input 3
0.0
•
16#80
•
Parameter
A.4 Block parameter MMMeas
