1.7

Example configurations

1.7.1

SIMOCODE pro PROFIBUS and PROFINET Configuration

SIMOCODE pro PROFIBUS and PROFINET configurations
Note
SIMOCODE pro is used in DP mode DPV1 with activated diagnostics and process interrupt.
The SIMOCODE pro PROFIBUS and PROFINET devices along with their associated
components are inserted and configured in HW Config.
The following graphics show example configurations of SIMOCODE pro at HW Config in the
Netpro View.
1.7.2

SIMOCODE pro PROFIBUS configuration

SIMOCODE pro C on DP master system
Figure 1-2
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
SIMOCODE pro C on DP master system
Introduction
1.7 Example configurations
21
