Siemens SIMOCODE pro Programming And Operating Manual page 281

Parameter Data format
P_Stop STRUCT
•
•
P_Rev STRUCT
•
•
P_FRev STRUCT
•
•
P_Rst STRUCT
•
•
LocalAct STRUCT
•
•
AutAct STRUCT
•
•
ManAct STRUCT
•
•
OosAct STRUCT
•
•
FbkFFwdOut STRUCT
•
•
FbkFwdOut STRUCT
•
•
FbkRevOut STRUCT
•
•
FbkFRevOut STRUCT
•
•
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Default setting
–
Value: BOOL 1
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 1
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
A.7 Block parameter MMRevDhl
Meaning
Pulsive Control Output to Stop
Pulsive Control Output to Start Motor Reverse
Pulsive Control Output to Start Motor Reverse
Reset Impulse
1 = Motor in Local Operation Mode: Local Mode Indicator
1 = Auto: Automatic Mode Indicator
Manual value is active
Out of service is active
Feedback of Control Fast Forward
0 = Stop
1 = Fast Forward
Feedback of Control Forward
0 = Stop
1 = Run
Feedback of Control Reverse
0 = Stop
1 = Run
Feedback of Control Fast Reverse
0 = Stop
1 = Fast Reverse
Parameter
281
