Description of the blocks
4.3 MMOprtn block
Table 4- 13
Parameter
DEVCLS
CNTLFUNC
THMSTR
ANLGMDL1
ANLGMDL2
TMPRMDL1
TMPRMDL2
ERTHMDL
VLTMDL
MLTFNCMDL
CURMOD
DGTLMDL1BI
DGTLMDL1MO
DGTLMDL2BI
DGTLMDL2MO
DGTLMDLFL
DGTLMDLFP
ERTHMDL2
104
UDT OPERATION
Data format
BYTE
BYTE
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Meaning
Device class
Control functions
Thermistor status
Analog module1 status
Analog module2 status
Temperature Module 1 status
Temperature Module 2 status
Earth fault module status
Voltage module status
Multi function module status
Current measuring module
Digital Module 1 Bi
Digital Module 1 Mo
Digital Module 2 Bi
Digital Module 2 Mo
Digital Module FL
Digital Module FP
Earth fault module status
SIMOCODE pro PCS 7 Library V9.0
