Siemens SIMOCODE pro Programming And Operating Manual page 261

Block parameters
RstEnrgyLi
OnOp
OosOp
OosLi
SampleTime
RunUpCyc
MsgEvId1
MsgLock
ExtMsg1
ExtMsg2
ExtMsg3
ExtMsg4
ExtMsg5
ExtMsg6
ExtMsg7
ExtMsg8
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Data format Default setting
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
BOOL FALSE
BOOL FALSE
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
REAL 0.1
INT 3
DWORD 16#FF
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
A.5 Block parameter MMStat
Meaning
input 0->1 = Reset Energy consumed
1 = On Mode: On Mode by Operator
1 = Oos Mode: Oos Mode by Operator
input 0->1 = Oos Mode: Oos Mode by Field Signal
Sampling Time [s]
Number of cycles for which all messages are sup-
pressed
Message Event ID 1
Inhibit process message
External message 1
External message 2
External message 3
External message 4
External message 5
External message 6
External message 7
External message 8
Parameter
261
