MMRevDhl block icons
The MMRevDhl block provides 2 block icons.
Table 3- 1
Number
1
2
MMOprtn block icons
The MMOprtn block provides the following block icons:
Table 3- 2
SIMOCODE pro control function
Overload relay
Direct starter /
soft starter
Reversing starter /
soft reversing starter
Star-delta starter
Star-delta reversing starter
Dahlander /
pole-changing starter
Dahlander reversing starter /
Pole-changing reversing starter
Solenoid valve
Positioners 1-5
The status display at the block icon depends upon the final status of the drive, but not on the
feedback received from the drive.
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
MMRevDhl block icons
Icon
MMOprtn block icons
Block icons and faceplate views
3.1 Block icons
Icon
PROFIBUS
PROFINET
