Parameter
A.2 Structure of UDTs for MMDiag
Element
EMSTRTACT
CLDNTMACT
IDLTMACT
DEVCHKACT
UMPHS123
UMPHS321
DMFCKT
SMCEVNT – event
Table A- 5 Event diagnostics information for SIMOCODE pro devices
Element
IMUMOVLOPRN
IMUMUNBAL
IMUMOVL
OVLPHSFAIL
INTGNDFLT
EXTGNDFLT
WRNGNDFLT
THRMOVL
THRMSHRT
THRMOPN
TMPWRNHI
TMPTRPHI
TMSNRERR
TMOUTRNG
CURWRNHI
CURWRNLO
PWRWRNHI
PWRWRNLO
COSPHIWRNLO
VOLWRNLO
WRN4TO20HI
WRN4TO20LO
CURTRPHI
CURTRPLO
PWRTRPHI
PWRTRPLO
COSPHITRPLO
VOLTRPLO
238
Data format Meaning
BOOL Emergency start executed
BOOL Cooling down period active
BOOL Pause time active
BOOL Device check active
BOOL Phase sequence 1-2-3
BOOL Phase sequence 3-2-1
BOOL DM-F enabling circuit closed
Data format Meaning
BOOL Pre-Warning overloaded
BOOL Unbalance
BOOL Overload
BOOL Overload and loss of phase
BOOL Internal earth fault
BOOL External earth fault
BOOL Warning external earth fault
BOOL Thermistor trip level
BOOL Thermistor short circuit
BOOL Thermistor open circuit
BOOL TM1 warning level T >
BOOL TM1 trip level T >
BOOL TM1 sensor fault
BOOL TM1 out of range
BOOL Warning level I >
BOOL Warning level I <
BOOL Warning level P >
BOOL Warning level P <
BOOL Warning level Cos-Phi <
BOOL Warning level U <
BOOL AM1 warning level 0/4-20mA >
BOOL AM1 warning level 0/4-20mA <
BOOL Trip level I >
BOOL Trip level I <
BOOL Trip level P >
BOOL Trip level P <
BOOL Trip level Cos-Phi <
BOOL Trip level U <
