Description of the blocks
4.6 Block for timestamping MMLog
4.6.5

Messages

The following application is only available for SIMOCODE pro PROFIBUS devices (
).
= 0
Signal messages and special messages
SIMOCODE detects three message buffers: DS12, DS13, and DS14. Each of these data
sets has 180 bytes to contain 16 messages.
Table 4- 84
Byte.Bit
0.0
12.0
24.0
...
180.0
Structure of a signal message
Table 4- 85
Byte.Bit
0.0
1.0
2.0
3.0
4.0
Up to 8 signal messages can be configured via SIMOCODE ES or EDD. To display the
signal messages, the timestamping must be activated in SIMOCODE ES or EDD.
188
Assignment
Description
Signal message or special message 1
Signal message or special message 2
Signal message or special message 3
...
Signal message or special message 16
Signal message assignment
Description Type
Slot number of mod- Byte[1]
ule
Channel number of Byte[1]
module
Signal status Byte[1]
Reserved Byte[1]
Time Byte[8]
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Size
12 bytes
12 bytes
12 bytes
...
12 bytes
IDs (important for SIMOCODE-III)
0x01: DPV1 slot model
0x04: S7 slot model
0x00 .. 0x07: Number of timestamping - Input
Bit 7:
1 = input signal = rising edge
0 = output signal = falling edge
Bit 6:
0 = Not used
0x00
Bit 0:
1 = Clock is synchronized,
0 = Clock is not synchronized
SIMOCODE pro PCS 7 Library V9.0
