Parameter
A.7 Block parameter MMRevDhl
Parameter Data format
RunFFwd STRUCT
•
•
RunFwd STRUCT
•
•
Stop STRUCT
•
•
RunRev STRUCT
•
•
RunFRev STRUCT
•
•
Starting STRUCT
•
•
Stopping STRUCT
•
•
OS_PermOut DWORD
OS_PermLog DWORD
OpSt_Out DWORD
Status1 DWORD
Status2 DWORD
Status3 DWORD
Status4 DWORD
ST_Worst BYTE
AutoST BYTE
ErrorNum INT
MsgErr1 BOOL
MsgStat1 WORD
MsgAckn1 WORD
MsgErr2 BOOL
MsgStat2 WORD
MsgAckn2 WORD
ReserveOut WORD
282
Default setting
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
16#FFFFFFFF
16#FFFFFFFF
16#00000000
16#00000000
16#00000000
16#00000000
16#00000000
16#80
16#80
-1
FALSE
16#00
16#00
FALSE
16#00
16#00
16#00
Meaning
1 = Motor running with Fast Forward
1 = Motor running forward
1 = Motor STOP
1 = Motor running reverse
1 = Motor running with Fast Reverse
1 = Motor starting
1 = Motor stopping
Operator Permission: Output for OS
Operator Permission: Output for OS
Enabled operator stations
Status1 Word
Status2 Word
Status3 Word
Status4 Word
Worst Signal Status
Worst Signal Status of the Automatic Commands
Error Number
1 = Messaging Error Occurs
Message status 1
Message acknowledgement status 1
1 = Messaging Error Occurs
Message status 2
Message acknowledgement status 2
Reserved
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
SIMOCODE pro PCS 7 Library V9.0
