Parameter
A.5 Block parameter MMStat
Output parameters for SIMOCODE pro PROFINET devices
Table A- 18 Output parameters MMStat – PROFINET devices
Parameter
Tmr5Act
Tmr6Act
Cnt5Act
Cnt6Act
CalMod3Out
CalMod4Out
AnaMulOut
266
Data format Default setting
STRUCT –
Value: REAL 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: REAL 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: DINT 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: DINT 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: REAL 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: REAL 0.0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: REAL 0.0
• •
ST: BYTE 16#80
• •
Meaning
Tmr5Act Actual Value in sec
Tmr6Act Actual Value in sec
Counter5 Actual Value
Counter6 Actual Value
Calculation module 3 – Output
Calculation module 4 – Output
Analog Multiplexer – Output
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
SIMOCODE pro PCS 7 Library V9.0
