4.6.4

Logbook function

The error buffer is available for SIMOCODE pro C / S / V PROFIBUS and PROFINET.
The error buffer contains the tripping events and events that a SIMOCODE pro device has
saved.
A maximum of 21 messages are recorded and displayed in the Logbook view (Page 195).
Each message contains the following attributes:
Attributes
Tripping events
Output
Output
Text of the message
Events
Output
Output
Text of the message
Date and real time are logged, if there is a valid time that has been synchronized via an NTP clock
1
or set manually with SIMOCODE ES.
When using DM-F expansion modules with SIMOCODE pro V.
2
Data records
The values are read from the SIMOCODE pro device with the "RDREC" function. This
information is written to the output parameters.
No.
1
2
3
4
Note
The user can suppress the reading of these datarecords by selecting the Feature.Bit26 = 1.
In that case, the data is not read from the device. Also the Logbook view button will be
disabled at the Faceplates.
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
to
LogId1 LogId21
to
LogTm1 LogTm21
2
EnCktCls / EnCktOpn
ClsTmStmp / OpnTmStmp
Data rec- Read ac-
ord num- cess/write
ber access
DS72 R
DS73 R
DS76 R
DS77 R
PROFIBUS devices
Number of the message
Operating hours of the
device
Type of the message
Time stamp
Number Description
of bytes
125 Read tripping event
165 Read event (DM-F)
193 Time stamp for tripping
event
193 Time stamp for events
(DM-F)
Description of the blocks
4.6 Block for timestamping MMLog
PROFINET devices
Number of the message
Real-time stamp
Type of the message
Time stamp
For For
PROFIBUS PROFINET
Yes Yes
Yes Yes
No Yes
No Yes
1
185
