OCX1100 Switch Hardware Guide
Table 26: AC Power Cord Specifications for 460 W AC Power Supplies for an OCX1100
Switch (continued)
Country/
Electrical
Region
Specifications
Taiwan
125 VAC, 10 A, 50 Hz
United
250 VAC, 10 A, 50 Hz
Kingdom
Related
Documentation
DC Power Supply Specifications for OCX1100 Switches
Table 27: DC Power Supply Specifications for an OCX1100 Switch
Item
DC input voltage
DC input current rating
Output power
44
Plug Standards
NEMA 5-15P Type N5-15P
BS 1363/A Type BS89/13
CAUTION:
The AC power cord for the OCX1100 switch is intended for use
with this switch only. Do not use the cord with any other product.
CAUTION:
Power cords must not block access to switch components.
AC Power Supply in OCX1100 Switches on page 23
Connecting AC Power to an OCX1100 Switch on page 80
General Safety Guidelines and Warnings on page 137
General Electrical Safety Guidelines and Warnings on page 165
Prevention of Electrostatic Discharge Damage on page 167
OCX1100 switches support 800 W DC power supplies.
Table 27 on page 44
lists the power supply specifications for a DC power supply used in
an OCX1100 switch.
Specifications
Nominal operating voltage: –40.5 VDC
Operating voltage range: –40.5 VDC through –60 VDC
4 A maximum at nominal operating voltage (–40.5 VDC)
800 W
Juniper Model Number
Graphic
CBL-EX-PWR-C13-TW
CBL-EX-PWR-C13-UK
Copyright © 2017, Juniper Networks, Inc.
