OCX1100 Switch Hardware Guide

Back-to-Front Airflow

20

Figure 11: Front-to-Back Airflow Through OCX1100-48SX Switch Chassis

You must install only power supplies that have
the fan modules have AIR OUT (AFO)
In the OCX1100 switch models that have back-to-front airflow, the air intake to cool the
chassis is through the vents on the rear panel and hot air exhausts through the vents on
the front panel of the switch. See
Figure 12: Back-to-Front Airflow Through the OCX1100-48SX Switch
Chassis
You must install only power supplies that have
the fan modules have
AIR IN (AFI)
AIR OUT (AFO)
labels.
Figure 12 on page 20.
labels in switches in which
AIR IN (AFI)
labels.
Copyright © 2017, Juniper Networks, Inc.
labels in switches in which
