OCX1100 Switch Hardware Guide
Table 14: Details of the AC Power Supplies in OCX1100-48SX Switches
Details
Model number
Field-replaceable unit (FRU) type
Power supply weight
Minimum installed in chassis
Maximum installed in chassis
Power supply slots
AC appliance Inlet
NOTE:
Each AC appliance inlet requires a
dedicated AC power feed.
Fans
Airflow
Power supply status LEDs
Operating range
24
Figure 13: AC Power Supply for an OCX1100 Switch
Table 14 on page 24
lists the details of the 460 W AC power supplies used in
OCX1100-48SX switches.
Number
Type
Rating
To prevent electrical injury while installing or removing AC power supplies, carefully follow
instructions in
"Installing an AC Power Supply in an OCX1100 Switch" on page 77
"Removing an AC Power Supply from an OCX1100 Switch" on page
460 W AC Power Supply
OCX-460W-X-AC-AFO
OCX-460W-X-AC-AFI
Hot-insertable and hot-removable
1.9 lb (0.861 kg)
2
2
Install in power supply slots labeled
in the rear panel of the chassis.
1
IEC-320-C13
2 A
Internal
Front-to-back, indicated by label
Back-to-front, indicated by label
One bicolor LED.
100–240 VAC
Copyright © 2017, Juniper Networks, Inc.
PSU 0
and
PSU 1
AIR OUT (AFO)
AIR IN (AFI)
and
111.
