Cable Specifications

Table 30: Software Support for SFP+ Passive Direct Attach Cables for OCX1100 Switches

Switch

OCX1100-48SX-AFO

OCX1100-48SX-AFI

OCX1100-48SX-D-AFO

OCX1100-48SX-D-AFI

This topic describes:

Cable Specifications on page 51

Standards Supported by These Cables on page 53

OCX1100 switches support SFP+ passive direct attach cables. The passive Twinax cable

is a straight cable with no active electronic components. OCX1100 switches support cable

lengths of 3 ft (1 m) and 10 ft (3 m) long SFP+ passive direct attach cables.

Table 30 on page 51

describes the support for SFP+ passive direct attach cable lengths

on OCX1100 switches for Junos OS releases.

Software Support Added

Junos OS Release 14.1X53-D20

NOTE:

We recommend that you use only SFP+ direct attach cables purchased

from Juniper Networks with your Juniper Networks device.

CAUTION:

If you face a problem running a Juniper Networks device that uses

a third-party optic or cable, the Juniper Networks Technical Assistance Center

(JTAC) can help you diagnose the source of the problem. Your JTAC engineer

might recommend that you check the third-party optic or cable and potentially

replace it with an equivalent Juniper Networks optic or cable that is qualified

for the device.

The cables are hot-removable and hot-insertable: You can remove and replace them

without powering off the switch or disrupting switch functions. A cable comprises a

low-voltage cable assembly that connects directly to two SFP+ ports, one at each end

of the cable. The cables use high-performance integrated duplex serial data links for

bidirectional communication and are designed for data rates of up to 10 Gbps.

Table 31 on page 52

describes the cable specifications.

Chapter 7: Transceiver and Cable Specifications

Cable Length

3 ft (1 m) and 10 ft (3 m)
