Characteristics of a DC Power Supply
Table 16: Details of the DC Power Supplies in OCX1100-48SX Switches
Details
Model number
Field-replaceable unit (FRU) type
Power supply weight
Minimum installed in chassis
Maximum installed in chassis
Power supply slots
Fans
Airflow
Power supply status LED
Operating range
26
This topic includes:
Characteristics of a DC Power Supply on page 26
The DC power supplies for OCX1100 switches are available in two models;
OCX-800W-X-DC-AFI and OCX-800W-X-DC-AFO.
power supply for an OCX1100 switch. Both are 800 W models, one with AFO airflow and
the other with AFI airflow.
Figure 14: DC Power Supply for an OCX1100 Switch
Table 16 on page 26
lists the details of the 800 W DC power supplies used in
OCX1100-48SX switches.
Figure 14 on page 26
800 W DC Power Supply
OCX-800W-X-DC-AFI
OCX-800W-X-DC-AFO
Hot-insertable and hot-removable
1.7 lb (0.771 kg)
2
2
Install in power supply slots labeled
in the rear panel of the chassis.
Internal
Front-to-back, indicated by label
Back-to-front, indicated by label
One bicolor LED.
–40.5 through –60 VDC
Copyright © 2017, Juniper Networks, Inc.
shows a DC
and
PSU 0
PSU 1
AIR OUT (AFO)
AIR IN (AFI)
