Field-Replaceable Units in OCX1100 Switches

Related
Documentation

Chassis Status LEDs on OCX1100 Switches

12
Field-replaceable units (FRUs) are components that you can replace at your site. The
FRUs in OCX1100 switches are hot-removable and hot-insertable: You can remove and
replace them without powering off the switch. The FRUs in OCX1100 switches are:
Power supplies
Fan modules
Transceivers
NOTE: Transceivers are not part of the shipping configuration. If you want
to purchase transceivers, additional power supplies, or fan modules for your
switch, you must order them separately.
NOTE: If you have a Juniper J-Care service contract, register any addition,
change, or upgrade of hardware components at
https://www.juniper.net/customers/support/tools/updateinstallbase/
to do so can result in significant delays if you need replacement parts. This
note does not apply if you replace existing components with the same type
of component.
Installing and Removing OCX1100 Switch Hardware Components on page 74
An OCX1100 switch has four chassis status LEDs (labeled
FAN ) on the left of the chassis, next to the

Figure 5: Chassis Status LEDs in an OCX1100-48SX Switch

1— STAT
2— LOCATOR
,
LOCATOR
RESET button (see Figure 5 on page
3— PWR
4— FAN
Copyright © 2017, Juniper Networks, Inc.
. Failure
, , and
STAT PWR
12).
