7
Push the tray in gently until it stops.
Note

Loading Envelopes

Envelopes can be loaded in Tray 5 (Bypass), the HCF B1-S (Tray 6), and the High Capacity
Feeder C3-DS (Trays 6 and 7).
Important • Envelopes can be loaded in Trays 1 to 3, but paper feed and print quality are not guaranteed.
The following size envelopes can be loaded.
Standard Size
- No.3 standard envelopes
- No.2 standard envelopes
- No.6 standard envelopes
- No.20 standard envelopes
- C5
- C4
- Commercial #10
Non-Standard Size
- Width (Y) 98.0 - 330.2 mm, Length (X) 148.0 - 488.0 mm
Note
When the envelope width is less than 182 mm, be sure to attach the Post Card Kit to the HCF
B1-S (Tray 6) or the High Capacity Feeder C3-DS (Trays 6 and 7).
The following describes how to load envelopes in the High Capacity Feeder C3-DS (Tray 6)
as an example.
The procedure is the same as for the HCF B1-S (Tray 6) and the High Capacity Feeder C3-DS
(Tray 7).
For how to load an envelope in Tray 5 (Bypass), refer to "Loading Paper in Tray 5 (Bypass)" (P.106).
Important • The number of sheets that can be loaded varies depending on the type of envelopes. For more
Note
• When removing the HCF Post Card Kit from
the tray, completely loosen the screw before
removing the kit. Place the removed HCF Post
Card Kit back to its original location (1). Then,
tighten the screw (2) for storing
(120 x 235 mm)
(240 x 332 mm)
(162 x 229 mm)
(229 x 324 mm)
(162 x 229 mm)
(229 x 324 mm)
(104.8 x 241.3 mm)
• When loading envelope in LEF orientation, or when loading envelope with the flap opening, use the
custom size setting.
• The length (X) of 146.0 to 147.9 mm is also supported, but the image quality and paper feed
performance are not guaranteed.
information, contact our Customer Support Center.
• Carefully fan the paper before loading it in a tray. Otherwise, paper jams may occur or multiple
sheets may be fed to the machine simultaneously.
• When loading envelopes, you need to set the paper type for the paper tray to [Uncoated] or
[Uncoated Reload], and the paper weight corresponding to the envelope loaded in the tray. For the
setting, refer to "Changing the Paper Settings" (P.123).
Loading Tab Paper/Postcards/Envelopes
