21 Maintenance

Executing Calibration

The machine can automatically calibrate colors using the calibration chart when the
reproducibility of density or color in copies and prints deteriorates. The machine can adjust
the gradation for each screen type set in the machine in advance.
The following four types of screen are available.
Note
Combination of Setting
Note
21
The following describes how to perform calibration.
1
Select [Calibration] on the Services Home
screen.
If [Calibration] is not displayed, follow the
procedure below.
682
• Copy Job 1
Calibrates the screen for [Text] or [Map] of [Original Type].
• Copy Job 2
This is the original screen for copying.
Calibrates the screen for [Photo & Text] or [Photo] of [Original Type].
• Print Job 1
This screen is the basic function for printer job. Calibrates the screen for Multi-model Print Driver 2.
• Print Job 2
- Calibrates the screen on Multi-model Print Driver 2 when the following combinations are specified.
Tab Image Options
Item Image Quality
Standard
• We recommend executing auto calibration for all four screen types. When the adjustment for one
screen type is complete, specify the next screen type and repeat the procedure.
• If color is not calibrated despite the periodic execution of auto calibration, contact our Customer
Support Center.
• Confirm the settings of the following items under [Tools] > [System Settings] > [Copy Service
Settings] > [Copy Defaults] in the System Administration mode before executing auto calibration:
- Lighten/Darken: Normal
- Contrast: Normal
- Sharpness: Normal
- Saturation: Normal
- Color Balance: 0, 0, 0
- Color Shift: Normal
• After finishing the auto calibration, change the settings of [Copy Defaults] if necessary. For
information on [Copy Defaults], refer to "Copy Defaults" (P.458).
Advanced Settings
Print Page Mode
On
