Fuji Xerox Versant 80 Press User Manual page 69

4
Press the main power switch to the [
5
Connect the network cable to the Ethernet interface connector.
Note • Always use the correct network cable with your network connection. When you replace the cable,
contact our Customer Support Center.
When the Secondary Ethernet (optional) is
not installed
Note • To use the connector as 1000BASE-T, the
Gigabit Ethernet (optional) is required.
When the Secondary Ethernet (optional) is
installed
Note • The Secondary Ethernet connector supports
1000BASE-T only.
• To use the standard Ethernet connector as
1000BASE-T, the Gigabit Ethernet (optional)
is required.
6
Press the main power switch to the [ | ] position
to switch on the main power.
7
Close the machine front door.
8
Press the power switch to switch on the power.
For more information on setting items, refer to "Printer Environment Settings" (P.563).
] position to switch off the main power.
Interface Cables
2
69
