21 Maintenance

Replacing the Booklet Staple Cartridge

When the Finisher C3 with Booklet Maker (optional) or the Finisher D4 with Booklet
(optional) is installed and the booklet staple cartridge needs to be replaced, a message
appears on the touch screen. When the message appears, replace the booklet staple
cartridge with a new one.
The following shows the reference section.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and performance.
Note
When the Finisher C3 with Booklet Maker is installed
1
Make sure that the machine is not operating,
and open the finisher front door.
21
2
Pull out the booklet unit.
3
With grasping the lever of the booklet staple
cartridge ([R2] or [R3]), push the booklet staple
cartridge downward. Then, pull out the booklet
staple cartridge upward.
670
When the Finisher C3 with Booklet Maker is installed........................................................................................................ 670
When the Finisher D4 with Booklet is installed .................................................................................................................... 672
Use only staple cartridges recommended by Fuji Xerox for the machine.
• To order a staple cartridge, contact our Customer Support Center.
• When the booklet staple cartridge is not replaced properly, the message remains on the touch
screen. Follow the procedure and replace the booklet staple cartridge again.
R3
R2
