Fuji Xerox Versant 80 Press User Manual page 469

Print Mode
Select the printer language use on the machine. Selecting [Auto] enables the machine to
automatically determine and use the most suitable language to print data received from
the host device.
PJL
PJL (Printer Job Language) is a job control language and a PJL command is data prepended
to the top of the print jobs. Usually select [Enabled].
Auto Eject Time
Configure the time that the data so far received by the machine will automatically be
printed since data is no longer sent to the printer.
You can enter a time between 5 and 1275 seconds in 5 seconds increments.
LPD
Port Status
Select [Enabled] to use LPD.
Port Number
Enter a port number for LPD from 1 to 65535.
The default value is 515.
Important • Do not use the numbers assigned to the other ports.
Maximum Number of Sessions
Enter the maximum number of client sessions using LPD. You can enter a number from 1 to
10 in 1 session increments.
The default value is 5.
SMB Client
Port Status
Select [Enabled] to use SMB when you use the Scan to PC (SMB) service or SMB
authentication service.
IPP
Port Status
Select [Enabled] to use IPP.
Set this when you want to use IPP (Internet Printing Protocol) to print via the Internet.
Added Port Number
Select [Disabled] when you want to set the machine does not accept IPP from other than
the standard port number, or select [Enabled] when accepts all port numbers.
Enter a port number for IPP other than the standard port number from 1 to 65535.
The default value is 80.
Important • Do not use a number that is the same as a port number of another port. However, you can use the
Note
same port number for a port that uses HTTP (IPP, Internet Services (HTTP), UPnP Discovery, SOAP,
WebDAV, and Web Services on Devices (WSD)).
• [Added Port Number] cannot be configured if [Port Status] is set to [Disabled]. To configure [Added
Port Number], enable port status and reboot the machine, and then configure [Added Port Number].
Connectivity & Network Setup
469
13
