Introduction
1.2.6
Remote Control
The operator may configure and monitor the modem from the front panel, or through the
remote M&C port. M&C is via RS-232, RS-485 (2/4 wire) or 10/100 BaseT Ethernet.
1.3
Major Assemblies
Assembly
PL/10570-1
PL/10570-2
PL/10070-1
PL/10069
PL/10073
PL/11128
PL/10635
PL/10071
PL/10072
AS/11014
PL/10678
PL/10697
PL/10698
PL/12608-1
PL/10898-1
PL/10416-1
PL/10416-2
PL/12798-1
PL/12798-2
1.4
FAST Options and Hardware Options
The Modem is extremely flexible and powerful, and incorporates a large number of
optional features. Some customers may not require all of these features, and therefore, in
order to permit a lower initial cost, the Modem may be purchased with only the desired
modules and features enabled. If, at a later date, a customer wishes to upgrade the
functionality of a modulator or demodulator, Comtech EF Data provides a system known
as FAST (Fully Accessible System Topology) which permits the purchase and
installation of options through the use of special authorization codes entered through the
front panel, or remotely.
The base configuration of the modulators and demodulators are equipped with Viterbi
and R-S codecs. It offers modulation types, and data rates up to 5 Mbps. It is, however,
limited to Closed Network operation.
Description
1 PPM Reference IF Backplane 70/140 MHz IF
0.1 PPM Reference IF Backplane 70/140 MHz IF
0.1 PPM Reference IF Backplane L-Band IF
Digital Backplane
Monitor and Control Card
70/140 MHz IF Modulator
70/140 MHz IF Demodulator with Carrier in Carrier
L-Band IF Modulator
L-Band IF Demodulator with Carrier in Carrier®
Turbo Codec – Simplex
EIA-530 Duplex Data interface
G.703 Balanced Duplex Data Interface
G.703 Unbalanced Duplex Data Interface
Quad E1 G.703 Data Interface Module
EIA-612/613 HSSI Interface
AC Chassis, 70/140 IF
DC Chassis, 70/140 IF
AC Chassis, L-Band
DC Chassis, L-Band
1–4
Revision 6
MN/CDMQx.IOM
