CDM-Qx Satellite Modem
Remote Control
Command
Parameter
(Instruction
Type
Code and
qualifier)
CnC Ratio Monitor
N/A
CnC Delay Monitor
N/A
CnC Freq Offset
N/A
Monitor
Software Revision
N/A
Arguments for
Command or
Response to
Query
4 bytes
Query only
When CnC is enabled and it's locked, it monitors the ratio between
the interferer and the desired power in dB.
Example 1: CRM==+02 (interferer > desired)
Example 2: CRM=LT10 (less than –11 dB)
Example 3: CRM=GT10(greater than +11 dB)
Example 4: CRM=99.9 (not locked or CnC not enabled)
7 bytes
Query only
When CnC is enabled and it's locked, it monitors the delay of the
interferer in microseconds.
Example 1: CDM=229,500 (229.5 ms)
Example 2: CDM=999,999 (not locked or CnC not enabled)
6 bytes
Query only
When CnC is enabled, an estimated frequency offset between
desired and interferer will be calculated.
Unit is in kilohertz ( kHz).
Example 1: CFM=+001.0 (1 kHz)
Example 2: CFM=9999.9 (not locked or CnC not enabled)
34-37 bytes
Query only
Units returns the value of the internal software revision installed in
the unit, in the form:
Boot:x.y.z Bulk1:x.y.z Bulk2:x.y.z
or
Boot:x.y.zz Bulk1:x.y.zz Bulk2:x.y.zz
Description of Arguments
C-31
Response to
Query
Command
(Instruction
(Target to
Code and
Controller)
Qualifier)
N/A
CRM?
N/A
CDM?
N/A
CFM?
N/A
SWR?
Revision 6
MN/CDMQx.IOM
Response to
query
(Target to
Controller)
CRM=xxxx
(see description of
arguments)
CDM=xxx.xxx
(see description of
arguments)
CFM=xxxx.x
(see description of
arguments)
SWR=Boot:x.y.zz
Bulk1:x.y.zz
Bulk2:x.y.zz
(see description of
arguments)
