CDM-Qx Satellite Modem
Front Panel Operation
Para. Title
5.6 Opening Screen
5.7 Main Menu
5.7.1 Config:
Config → Remote
5.7.11
Config → Tx
5.7.1.2
Config → Rx
5.7.1.3
Config → Group
5.7.1.4
Config → Frame
5.7.1.5
Config → Interface
5.7.1.6
Config → Ref
5.7.1.7
Config → Mask
5.7.1.8
Config → ODU
5.7.1.9
5.7.2 Monitor
Monitor → Alarms
5.7.2.1
Monitor → Rx-Params
5.7.2.2
Monitor → Event-Log
5.7.2.3
Monitor → Stats
5.7.2.4
Monitor → AUPC
5.7.2.5
Monitor → CnC
5.7.2.6
Monitor → ODU
5.7.2.7
5.7.3 Test
5.7.4 Info
5.7.5 Save/Load
5.7.6 Utility
5.7.7
Utility→FAST
5.5

Accessing the Display Area

Since the front panel display screen is split into two, the left-hand display area (also
called as the slot screen) can be accessed by using the ◄ arrow key if the menu-level is
MAIN, CONFIG, MONITOR, or INFO (and there is more than one module to select
between).
To go back to the right-hand display area (also called the menu screen), just press
CLEAR

Table 5-2. Prinicpal Menu Tree

Remarks
Select: Config; Monitor; Test; Info; Save/Load; Util; ODU
Select: Remote; Tx; Rx; Group; Frame; Interface; Ref; Mask; ODU
Select: Local; Serial; Ethernet
Select: FEC; Mod; Code; Data; Freq; On/Off; Pwr; Scram; Clk; Inv; Txα
Select: FEC; Demod; Code; Data; Freq; Acq; Descram; Buf; Inv; Misc; CNC
Select: Modem; Redundancy
Select: Unframed; EDMAC; EDMAC-2; D&I++
Select: RS422; V.35; RS232; HSSI; ASI; G.703; QDI; None
Select: Internal; 10MHz
Select: Transmit; Receive; Reference; BUC; LNB
Select: BUC; LNB
Select: Alarms; Rx-Params; Event-Log; Stats; AUPC; CNC; ODU
Select: Transmit; Receive; Unit; ODU
Select: Eb/No, BER, ΔF, BUF, RSL
Select: View; Clear-All
Select: View; Clear-All; Config
Framing is required for AUPC Monitor
Carrier in Carrier® (CnC) is not locked.
Select: ODU; LNB
Select: Mode; BIST; Spec-Analyzer
Select: Rem; Tx; Rx; Buffer; Frame; Interface; Mask; Ref; ID
Select: Save; Load
Select: RxBuffer; Clock; Ref; ID; Display; Firmware; FAST
Select: Base; Slot1; Slot2; Slot3; Slot4
. By pressing
or
ENTER
, the user has selected the plug-in card.
ENTER
