CDM-Qx Satellite Modem
Remote Control
C.5.8
Built-in BERT commands (BER Tester)
Command
Parameter
(Instruction
Type
Code and
Qualifier)
Built-in BERT
BST=
state (applies to
card-by-card
basis)
BERT Config
BCP=
Pattern state
(applies to card-
by-card basis)
BERT Restart
BRM=
Monitor (applies to
Rx card)
BERT 10E-3 Error
BKE=
Insert (applies to
Tx card)
BERT Config Sync
BCT=
Loss Threshold
(applies to Rx
card)
BERT Result in bit
N/A
errors (applies to
Rx card)
Arguments for
Command or
Response to
Query
1 byte, value of 0
Command or Query
and 1
State of built-in tester (BST), where:
0=Off
1=On
1 byte
Command or Query
Syntax: BCP=x, where x=BERT pattern
BERT Pattern:
0 = space
1 = mark
2 = 1:1
3 = 1:3
4 = 63
5 = 511
6 = 2047 (default)
7 = 2047R (or 2047 Alternate)
8 = Mil 188
9 = 2^15-1
A = 2^20-1
B = 2^23-1
1 byte, value of
Command only.
1 only
Restarts or resets the BERT monitor.
Example: BRM=1
1 byte, value of
Command or Query.
0, 1
Inserts 10E-3 BER.
0 = Off
1 = On
Example: BKE=1
1 byte, value of 0
Command or Query.
to 3
BERT config sync loss threshold.
0 = 256 bit errors counted in less than 1000 bits o data
1 = low (100 bit errors in less than 1000 bits of data)
2 = med (250 bit errors in less than 1000 bits of data)
3 = high (20,000 bit errors in less than 100,000 bits of data)
7 bytes, numeric
Query only.
BERT monitor results in bit errors. If bit errors exceed 9999999, then
BRE=9999999.
Description of arguments
C-40
Response to
Query
Command
(Instruction
(Target to
Code and
Controller)
Qualifier)
BST=
BST?
BST?
BST*
BST#
BST$
BST^
BCP=
BCP?
BCP?
BCP*
BCP#
BCP$
BCP^
BRM=
N/A
BRM?
BRM#
BRM$
BRM^
BRM@
BKE=
BKE?
BKE?
BKE#
BKE$
BKE^
BKE@
BCT=
BCT?
BCT?
BCT#
BCT$
BCT^
BCT@
N/A
BRE?
Revision 6
MN/CDMQx.IOM
Response to query
(Target to
Controller)
BST=x
(see description of
arguments)
BCP=x
(see description of
arguments)
N/A
BKE=x
(see description of
arguments)
BCT=x
(see description of
arguments)
BRE=xxxxxxx
(see description of
arguments)
