FINAL INSTALLATION SETUP

Exiting Programming (System
Configuration)
After programming the Control Panel, all the changes need
to be saved in memory. After saving, the programmed
settings will remain in memory, even after a total power
loss.
After setting all the required programming values for
1
the sensors and the Control Panel, press End.
2 Review the Summary of System Configuration screen.
Use the ↓ and ↑ arrows to scroll through the lis ng.
Verify that each option is set correctly.
To save the programming changes, be sure the Save
3
Changes option is checked. To exit without saving
programming changes un‐check the Save Changes
option (for verification, an additional confirmation
screen appears). Press Exit.
The Control Panel takes a few seconds to restart and
4
display the Home screen.

Customizing the Installation

After programming the Control Panel, go to the User
Toolbox and customize the system to suit the installation. To
access the User Toolbox, do the following:
From the Home screen, press Security.
1
From the Security screen, press, Menu.
2
From the Menu screen, Press Toolbox.
3
4 Enter the master user code (the default master user
code is 1111).
Press User Management.
5
6 To add, change, or delete a user code, press a User #
button. The system asks to confirm the code entered.
Be sure to set a Duress Code as User #8.
NOTE: User codes 0000, 0001, and the Installer Code are
not permitted.
Setup each user code with the User Access Option
7
screen. Each User Code can be set to be currently valid
or not, or to have conditional validity. Refer to the User
Guide for details on setting User Code Access Schedules.
When done, press Back.
Press Brightness/Volume. Set the level for the display
8
brightness. Set the chime & voice volume. When done,
press OK.
9 To view the 2nd Toolbox screen, press →. To set the
display lighting timeout, press Back Light Timeout.
Choose the length of time that the display will remain
lit after it is idle. When done, press OK.
10 To set the calendar and the clock press Set Date and Set
Time.
On the Set Date screen, use the ↓ and ↑ arrows to set
the month, day, and year. On the Set Time screen, use
the ↓ and ↑ arrows to set the hours, minutes, and
AM/PM. When done, press OK. A confirmation screen
appears. Verify the time and date, then press OK again.
11 If the GSM (Cellular) Radio Module is properly installed
and registered, the system automatically sets the date
and time.
• To return to the Security screen, press Back.
OR
• To return to the Home screen, press the
Copyright © 2014 Linear LLC
Control Panel Programming
button.
67
