Go!Control Wireless Security System | Installation and Programming Guide
Summary of RF Keypad Screen
After setting all the options for a sensor, the RF keypad
summary screen is displayed. The screen can also be
displayed for programmed RF keypads by pressing the Sum
button.
• To return to programming, click the Edit Current or
Edit Next buttons.
• Pressing Skip goes to question Q5 (Control Panel
programming).
• To exit programming, click Skip then End and Exit.
Upon exit, the Control Panel takes several seconds
to restart.
RF Keypad Programming Questions
Q4: Select RF Keypad # (1 to 4)
Up to four (4) wireless keypads can be programmed for use
with each Control Panel. The options for each sensor are
programmed with sub‐option questions:
• Begin by entering the RF Keypad number or select it
using the ← or → arrows.
• Program the RF keypads by using the ↑ and ↓
arrows to select the sub‐options.
To skip RF Keypad programming, press Skip to jump from
question Q4 to question Q5 (Exit Delay programming).
Q: Select RF Keypad (#) Used (0 to 1)
DEFAULT: (0) Unused
Users can use RF keypads together with a Control Panel or
not.
• The default setting (0) Unused sets all RF keypads as
unused.
• To enable programming for this RF keypad, select
(1) Used.
Q: Select RF Keypad (#) Equipment Code (0-9999)
DEFAULT: (0000) Other
The RF keypad equipment code defines the sensor's
manufacturer and type.
• The default setting is (0000) Other.
• Select (0867) 2GIG Wireless Keypad.
• Select (1059) 2GIG TS1 Wireless Touchscreen
Keypad.
NOTE: The 2GIG Wireless Touch Screen Keypad is not
intended for UL 985: Household Burglar‐Alarm System
Units installations.
Q: Enter RF Keypad # Other Equipment Code (0-9999)
DEFAULT: 0
NOTE: This question is only displayed if (0000) Other is
selected as the RF keypad's equipment code.
IMPORTANT: The equipment code is a four (4)‐digit code
that is assigned to the appropriate keypad model being
used.
• Enter the equipment code number for the RF
Keypad.
52 Copyright © 2014 Linear LLC
Q: Enter RF Keypad# Serial Number (7 Digits)
DEFAULT: 0000000
or
RF Keypad (#) Keypad ID (read‐only)
Serial numbers for standard wireless keypads can be
manually entered or learned from the keypad. For Wireless
Touch Screen Keypads, serial numbers can only be learned
from the keypad. Read‐only with Keypad ID's refer to the
installer being unable to manually input an id.
Standard Keypads:
• For manual entry, enter the Wireless Keypad that
was logged for the keypad being programmed.
Press the Shift button to access alpha characters.
• For automatic entry, press Shift and then Learn.
This places the Control Panel into learning mode.
When you trigger the keypad the sensor for the
keypad being programmed, it sends its serial
number to the Control Panel.
Wireless Touch Screen Keypads (only available in some
regions):
• For Wireless Touch Screen Keypads press Learn.The
Control Panel displays the "Pair with TS‐1. Initiating
learning process." Press the keypad's Pair with
Panel button. When complete, the keypad and the
Control Panel display "The learn operation
succeeded" message.
• The Control Panel displays "RF Keypad (#1‐4)" to
identify the keypad.
• The keypad displays "Network ID: xxxx" which is its
unique serial number.
• Press OK on both the Control Panel and the
Wireless Touch Screen Keypad to continue.
NOTE: The Wireless Touch Screen Keypad will display "The
security system is temporarily not operational" after
learning the Keypad. This is normal, and will be
displayed anytime the Control Panel is in system
configuration (programming) mode.
Q: Select RF Keypad# Equipment Age (0 to 1)
DEFAULT: (0) New
The Control Panel can be used with new or existing RF
keypads.
• If this RF Keypad is new for the installation, leave
the default of (0) New.
• If this RF Keypad is already installed, select (1)
Existing.
