PROGRAMMING NAVIGATION
When the installer is using the System Configuration
menus, the Control Panel will present each programming
question sequentially. Most programming questions have a
single numeric value response or a simple enabled/
disabled selection. Some programming questions have sub‐
options that can be set. These sub‐options are displayed
for the question selected and can be accessed through
navigation keys on the display.
NAVIGATION ARROWS & GO TO BUTTON
The programming question screens display up, down, left,
and right navigation arrows. Use these arrows to scroll
through the programming questions and to select sub‐
options.
Press the Go To button and then enter a two (2)‐digit code
to jump directly to a programming question. See
"Programming Question Table" on page 33. The Go To
button changes to Cancel when waiting for you to enter a
question number. Press Cancel to back out.
Figure 43 Navigation Arrows & Go To Button

QUESTIONS WITHOUT SUB-OPTIONS

Most of the programming questions do not have sub‐
options. They navigate as follows. Questions without sub‐
options do not display a Skip button.
Figure 44 Questions without Sub-options
• The ↑ and ↓ arrows select the next or previous
programming question.
• The ← and → arrows choose values for the ques on or
move the cursor left and right along the white data
entry field.
30 Copyright © 2014 Linear LLC

QUESTIONS WITH SUB-OPTIONS

Some of the programming questions have sub‐options.
They navigate as follows. Questions with sub‐options
display a Skip button during the question. The Skip button
advances to the next programming question/section.
• The ↑ and ↓ arrows select the next or previous
programming sub‐question.
• The ← and → arrows choose values for the ques on or
move the cursor left and right along the white data
entry field.
Figure 45 Questions with Sub-options
