Go!Control Wireless Security System | Installation and Programming Guide
Scroll between op ons using the ← and → arrows. Move to
the previous or next prompt by pressing the ↑ and ↓
arrows.
To program another sensor click Next.
1
To exit programming, click Skip then End and Exit. Upon
2
exit, the panel takes several seconds to restart.
*Only used for "other" equipment
**Press Insert for each word. To select from the list, you
can use the keypad or press the ← or → arrows.

Summary of RF Sensor # Screen

After setting all the options for a sensor, the RF sensor
summary screen is displayed. The screen can also be
displayed for programmed sensors during RF sensor
program editing by pressing the Sum button.
• While programming each RF sensor remember that
the ← and → arrow bu ons step through each of
the RF sensor numbers.
• To return to programming, click the Edit Current or
Edit Next buttons.
• Pressing Skip goes to question number Q2 (Wired
Sensor Programming). See "Wired Sensor
Programming" on page 45.
Figure 51 Summary of RF Sensor # Screen
42 Copyright © 2014 Linear LLC

RF Sensor Programming Questions

Q1: Select RF Sensor # (01-48)
Up to 48 wireless RF sensors can be used with each Control
Panel. The options for each sensor are programmed with
sub‐option questions.
Enter the RF sensor number or press the ← or → arrows
1
to select it.
Program the sensor details by using the ↑ and ↓
2
arrows to select each of the sub‐options.
NOTE: To skip Q1 and jump directly to Q2 for Wired Sensor
Programming, press Skip.
Q: Select RF Sensor # Type
DEFAULT: (00) Unused
Answer this question to define the sensor type (zone).
Simply enter the appropriate code (see table below) or
press the ← or → arrows to select the desired zone.
In the table below, a "Y" indicates the sensor type can be
assigned. A "N" indicates the sensor type is not used, and
an asterisk (*) denotes that selecting this sensor type also
requires you to answer the Q: Select RF Sensor # Equipment
Type question.
Sensor Types (Zones)
(00) Unused
(01) Exit/Entry 1
(02) Exit/Entry 2
(03) Perimeter
(04) Interior Follower*
(05) Day Zone
(06) 24‐Hour Silent Alarm*
(07) 24‐Hour Audible Alarm*
(08) 24‐Hour Auxiliary Alarm*
(09) 24‐Hour Fire
(10) Interior with Delay*
(14) 24‐Hour Carbon Monoxide
(16) 24‐Hour Fire Verification
(23) No Response Type*
(24) Silent Burglary
RF Wired
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Y N
Y Y
Y N
Y N
Y Y
Y Y
