Summary Of Rf Key Fob # Screen - 2gig Technologies Go!Control Panel Installation & Programming Manual

Summary of RF Key Fob # Screen
After setting all the options for a key fob, the Summary of
Fob # screen is displayed. The screen can also be displayed
for programmed sensors during wired sensor program
editing by pressing the Sum button.
• While programming each key fob remember that the ←
and → arrow bu ons step through each of the key fob
numbers.
• To return to programming, click the Edit Current or Edit
Next buttons.
• Pressing Skip goes to question number Q4 (RF Keypad
Programming). See "Wireless (RF) Keypad
Programming" on page 51.
RF Key Fob Programming Questions
Q3: Select Fob # (1 to 8)
Up to eight (8) wireless four (4)‐button key fobs can be used
with each Control Panel. Key fobs reports as sensors 51‐58.
The options for each fob are programmed with sub‐option
questions.
• Begin by entering the fob number or select it using
the ← or → arrows.
• Program the key fobs by using ↑ and ↓ arrows to
select the sub‐options.
NOTE: To skip RF key fob programming, press Skip to jump
from question Q3 to question Q4 (RF keypad
programming). See "RF Keypad Programming
Questions" on page 52.
Q: Select Fob # Used (0 to 1)
DEFAULT: (0) Unused
Key fobs can be used with the Control Panel or not.
• The default setting (0) Unused sets all key fobs as
unused.
• To enable programming for this key fob, select (1)
Used.
Q: Select Key Fob # Equipment Code (0-9999)
DEFAULT: (0000) Other
The key fob equipment code defines the sensor's
manufacturer and type.
• The default setting is (0000) Other.
• Select (0866) 2GIG 4‐button Key Fob remote for a
2GIG‐KEY2 key fob remote.
• Select (0577) Existing Key Fob remote for an existing
key fob remote.
NOTE: Only 2GIG 4‐Button Key Fob Remotes are compatible
with this system.
Q: Enter Key Fob # Other Equipment Code (0-
9999)
DEFAULT: 0
NOTE: This question is only displayed if (0000) Other is
selected for a key fob's equipment code.
• The equipment code is a four (4)‐digit code that is
assigned to the model of key fob being used.
• Enter the equipment code number for the key fob.
Q: Enter Fob # Serial Number(7 Digits)
DEFAULT: 0000000
Key fob serial numbers can be manually entered or learned
from the fob.
• For manual entry, enter the fob number that was logged
for the fob being programmed. Use the Shift button to
access alpha characters.
• For automatic entry, press Shift, then press Learn. The
Control Panel will wait for a fob transmission. Trigger
the fob being programmed and the Control Panel will
learn the fob's serial number.
Q: Select Fob # Equipment Age (0 to 1)
DEFAULT: (0) New
The Control Panel can be used with new or existing key
fobs.
• If this fob is new for the installation, leave the default
setting of (0) New.
• If this fob is already installed, select (1) Existing.
Q: Select Fob # Emergency Key (0 to 4)
DEFAULT: (0) Disabled
Pressing the and buttons on a key fob at the same
time for 5 seconds can trigger an emergency alarm.
• The default setting (0) Disabled inactivates the
emergency function the fob #.
• To enable the emergency function for this fob, select
one (1) of the four (4) options:
• (1) Auxiliary Alarm
• (2) Audible Alarm
• (3) Silent Panic
• (4) Fire
Q: Select Fob# Key # Can Disarm (0 to 1)
DEFAULT: (1) Enabled
As an installer, consult the user as to whether to set the key
fob to allow disarming the Control Panel with the key fob's
button. If the user wants the key fob used as a stationary
wall fob, it can also be set to prevent using the key fob to
disarm the system.
• The default setting (1) Enabled allows the fob to disarm
the system.
• To not allow the fob to disarm the system, select (0)
Disabled.
Q: Construct Fob# Voice Descriptor
DEFAULT: (#) Keyfob
The voice descriptor are the actual the words that the
Control Panel use for this fob for low battery
announcements and log entries. Up to five (5) words are
allowed.
Press Insert to place a word from the vocabulary into
1
the data entry field.
2 Use the ← or → arrows to scroll through the words, or
enter the word's three (3)‐digit index number.
Press Insert again for the next word. Up to five words
3
are allowed.
To remove a word, press Delete.
4
Copyright © 2014 Linear LLC
Installer Programming
49
