BR/BD 100/250 R BP / RI
4.0

Modular Electronic Control Circuits

Module networking
A6
FILTER
SHAKER USERPANEL
MODULE
A3
CLEANING- TRACTION
MODULE MODULE
Brushes Drive motor
Vacuum blower Magnetic brake
Metering Horn
cleaning agent
Seat switch
Water level
sensor
Gaspedal
Float switch
Direction switches
Module cross-linking with all options and service module
Service Manual 08.2007
A0
INFO/
Expansible, serial network cable (Bus)
A2 A4
LIFT
MODULE
Linear
actuators
Side broom
option
Micro switches
Modular Electronic Control Circuits
A1
– Operating system
MASTER
– Sequence of machine events
MODULE
– Error diagnosis/Debugging
A7
CHARGING ACCESSORY
MODULE
Battery charger
Charging
management
A5 A9
SERVICE
MODULE MODULE
Lights Diagnosis
Hydraulic Parameterizati-
valves on
Displaytext
Cabin options
download
Micro switches
Firmware
download
Page 65 / 171
