3.3.2.1 Driving (without cleaning functions)
Initial operation
Shutdown procedure
Switch program switch to Pos 1 (no cleaning components active)
Drive motor (M1)
active
Magnet brake
(YO) triggered
Note:
For more drive comfort the travel direction switch (S2) can be actuated as required with the drive pedal depressed. The
machine gently brakes to a stop and automatically accelerates in new selected direction.
Page 56 / 171
Display
Battery: E....F
Water/C: E....F
Drive motor
(M1) ready
Driver`s seat occu- no
pied?
(seat sensor S10)
yes
Travel direction
switch a (S2)
(forward/reverse)
Driver`s pedal no
pressed
(Magnet sensor B1)
yes
no Driver`s seat
previously vacated?
And occupied again?
yes
Drive motor (M1)
remains stopped
Display
„Release accelerator"
Release accelerator
Red LED parking brake active
Magnet brake (YO) active
BR/BD 100/250 R BP / RI
Drive motor (M1)
Stop
Magnet brake (YO) active
Red LED active
Service Manual 08.2007
