DB-209/210 ELECTRICAL PARTS LAYOUT DRAWING

PS102 Upper limit detect PS (upper)
PTC heater
3
* Treated as a spare parts in
the case of new type DB
SDB1 Size detection board 1
SDB1 Size detection board 2
M100 Paper feed motor
PS104 Jam detect PS1
PS107 Upper limit detect PS (lower)
SD101 1st paper feed SD (upper)
M101 Tray motor1
M102 Tray motor2
SD102 1st paper feed SD (lower)
PS103 No paper detect PS (upper)
PS108 No paper detect PS (lower)
PS105 Jam detect PS2
PS101 Tray detect PS (upper)
PS106 Tray detect PS (lower)
8-12
PFUDB PFU drive board
