Chapter 3 Serial Configuration
RS-422
Format: <KbRS-422>
RS-422:
0 = Disabled
Example: To enable RS-422, enter <Kb1>.
Note: Whenever RS-422 is disabled, RS-232 is enabled in the background.
However, an exception occurs whenever Multidrop has been selected. In this
case the functioning protocol will be RS-485 regardless of the displayed status
of RS-422 in the menus.

Operations Commands

Triggering Mode
Format: <Kgtriggering mode>
triggering mode:
0 = Continuous Read
1 = Continuous Read 1 Output
2 = External Level
Example: To select External Edge, enter <Kg3>.
End of Read Cycle
Format: <Khend of read cycle mode,timeout>
end of read cycle mode:
0 = Timeout
1 = New Trigger
2 = Timeout & New Trigger
Example: To select Timeout and change the timeout value to 6 seconds,
enter <Kh0,600>.
Serial Trigger Character
Format: <Kiserial trigger character>
serial trigger character:
Any available ASCII character (see "ASCII Table with Control
Characters" on page A-5). Default is ^].
1. Avoid selecting a serial trigger character that is also an operational command. For example, an upper-
case C cannot be used as a serial trigger character because it is the operational command for Enter
Read Rate Test. However, a lowercase c could be used without initiating the read rate test.
3-8
MS-610 Scanner User's Manual
1 = Enabled
3 = External Edge
4 = Serial Data
5 = Serial Data & Edge
timeout (in 10 millisecond increments):
Any number between 0 and 65535. Default is
100 (one second).
1
