Diagnostics and Troubleshooting
12TUser Manual
8.1

LED Status Indicators

Color
LED
Green
PRT1
Green
PRT2
Green
PRT3
Red
ERR1
N/A
ERR2
Red
ERR3
Green
Active
Red
BAT
If the module is not operating and the status LEDs are not illustrated in the table
above, please call ProSoft Technology for technical assistance.

8.1.1 Ethernet LED Indicators

State
LED
Off
Data
Green Flash
Off
Link
Green Solid
Page 94 of 136
Status Description
On Data is being transferred between the module and a remote
terminal using the Configuration/Debug port.
Off No data is being transferred on the Configuration/Debug port.
Port not used in application
On
Off Port not used in application
On Port not used in application
Port not used in application
Off
Off The PTQ-104C is working normally.
On The PTQ-104C module program has recognized an application
error.
Not used in application
On Configuration Error
On The LED is on when the module recognizes a processor and is
able to communicate if the [Backplane Data Movement] section
specifies data transfer commands.
Off The LED is off when the module is unable to communicate with the
processor. The processor either absent or not running.
Off The battery voltage is OK and functioning.
On The battery voltage is low or the battery is not present. The battery
LED will illuminate briefly upon the first installation of the module or
if the unit has been un-powered for an extended period of time.
This behavior is normal, however should the LED come on in a
working installation please contact ProSoft Technology.
Description
No activity on the Ethernet port.
The Ethernet port is actively transmitting or receiving data.
No physical network connection is detected. No Ethernet
communication is possible. Check wiring and cables.
Physical network connection detected. This LED must be on
solid for Ethernet communication to be possible.
49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
ProSoft Technology, Inc.
March 4, 2013
