49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
Item
Enable Code
Database Address
Poll Interval
Session Index
Sector Index
ProSoft Technology, Inc.
March 4, 2013
Description
Range
Enable/Disable Disable = Disables command
Enable = Enables command with Poll Interval in
seconds
Conditional = Executes command when point
value in database changes
This field specifies the location in the module's
internal database to associate with the
command. The Data Type (page 46) used in the
command determines addressing of the index
as follows:
Description
Data Type
45 Bit address, Single point command
46 Bit address, Double point command
47 Byte address, Regulating step point command
48 Word address, Setpoint normalized point
command
49 Word address, Setpoint scaled point command
50 Double-Word address, Setpoint short float point
command
51 Double-Word address, Bitstring (32-bits) point
command
100 *Word address, Group interrogation command
*Word address, Counter interrogation command
101
102 *Word address, Read command
103 *Word address, Clock synchronization
command
105 *Word address, Reset process command
107 *Word address, Test command (IEC-870-5-104
type)
110 Word address, Normalized measured value
111 Word address, Scaled measured value
112 Float (double-word), Short float value
113 *Word address, Activation command
*Word address = Value only used to signal
when to send event (Enable Code = 2)
1 to 65535 This parameter is used if the Enable Code field
is set to a value of 1. Delay (in seconds) to
execute this command since its last execution.
To be used if this command is to be executed
every X seconds.
0 to 3 This parameter is utilized to associate the
command with one of the sessions defined for
the module.
0 to 1 This parameter is used to associate the
command with the proper sector of the selected
session.
Module Configuration
