5.3.3 User-Constructed Command Block (9901)

Block identification code 9901 is used to issue one or more user-constructed
commands. When the module receives a block 9901 identification code, it will
place the included commands into the command queue.
Block Format from Processor (4x Register Data) to module
Word Offset in Block
0
1
2
3 to 8
9 to 14
15 to 20
21 to 26
27 to 32
33 to 38
39 to 44
45 to 50
51 to 56
57 to 62
63
Page 54 of 136
NTP Request Number of requests to NTP server
NTP Response Number of responses from NTP server
SNTP Number of times SNTP time computed
Computation
Number of times SNTP time set
SNTP Set
NTP Timeout Number of NTP response timeouts
Data Field(s) Description
Sequence This field contains a new value each time the user
Counter wishes to request a new command block.
Block ID This field contains the block identification code of
9901 for the block.
Command Count This field defines the number of user commands
contained in the block. The valid range for the field is
1 to 10.
Command #1 Data required to build the user defined command in
the command queue.
Command #2 Data required to build the user defined command in
the command queue.
Command #3 Data required to build the user defined command in
the command queue.
Command #4 Data required to build the user defined command in
the command queue.
Command #5 Data required to build the user defined command in
the command queue.
Command #6 Data required to build the user defined command in
the command queue.
Command #7 Data required to build the user defined command in
the command queue.
Command #8 Data required to build the user defined command in
the command queue.
Command #9 Data required to build the user defined command in
the command queue.
Command #10 Data required to build the user defined command in
the command queue.
Not used.
Spare
