Module Configuration
12TUser Manual
Item
Time DB Offset
Driver Status Offset:
5.6

[IEC-104 Client/Session x]

The [IEC-104 Client/Session x] section of PCB includes the client configuration
for up to four IEC-104C Clients on the module.
Page 62 of 136
Description
Range
-1 to 3994 -1: Disable
0-3994: Database location of IEC time
NOTE: Requires 6 registers
-1 to 3970 -1: Disable
0-3970: Database location of general client
driver status data
NOTE: Requires 30 registers
