Module Configuration
12TUser Manual
Item
Data Type
Point Index
Database Address
5.7

[IEC-104 Client Commands] section

This section defines the 104C Client commands to send to the remote
servers.
Page 68 of 136
Description
Range
ASDU type code in message
0 to 65535 Value for the Information Object Address (IOA)
0 to 64000 Database address in the module associated to
this point according to ASDU type:
Single-point: bit-addressing
Double-point: bit-addressing
Step-point: byte-addressing
Bitstring: double-word-addressing
Setpoint normalized: word-addressing
Setpoint scaled: word-addressing
Setpoint floating: double-word-addressing
Parameter normalized: word-addressing
Parameter scaled: word-addressing
Parameter float: double-word-address
Integrated BCD: 3-word-addressing
49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
ProSoft Technology, Inc.
March 4, 2013
