Event Pass-Through Block Format
The block that is copied from the module to the processor has the following
format. Each block can contain up to 4 events. The number of events per block
will typically depend on the rate between how fast the module receives the
events and how fast these can be passed to the processor (typically depends on
the processor scan rate).
Block Format for Read
Block Format from Module (%IW or 3x Register Data)
Word Offset in Block
0
1
2
3 to 16
17 to 30
31 to 44
45 to 58
59 to 61
62
63
The format of each 14 word data region in the block is shown in the following
table.
Word Offset
0
1
2
3
4 to 5
6
7
8
ProSoft Technology, Inc.
March 4, 2013
Data Field(s) Description
Sequence Counter This field contains a new value each time the
block is handled.
Block ID This field contains the block identification code of
9903 for the block.
Event Count This field contains the number of events present
in the block. Values of 1 to 4 are valid.
Event message
Event 1
Event 2 Event message
Event 3 Event message
Event message
Event 4
Spare Not used
Event count in queue Number of messages left in event buffer
Event Overflow Event buffer overflow
Description
Definitions
Session Index This field contains the session index used to
define the controlled unit in the module from
which the event was generated.
Sector Index This field contains the sector index used to
define the database within the controlled unit
from which the event was generated.
COT This field contains the COT for the event
message received from the IED. If the size of the
COT is a single byte, the originator address will
always be zero. The COT is in the LSB and the
originator address is in the MSB.
Reserved This field is reserved for future use and is added
here to keep the structure double-word aligned
for all platforms.
Point Index This field contains the point index in the remote
device that generated the event.
ASDU Type This field contains the ASDU type code for the
data contained in the message.
Milliseconds and This word contains the seconds and milliseconds
Seconds when the event occurred.
Minutes and Hours This field contains the minutes and hours the
event occurred.
