Reference
12TUser Manual
Word Offset
in Block
2
3
4
5
6-15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
Page 118 of 136
Data Field(s) Description
State State of Client Socket:
-255 = Idle until processor in run
-1
0
1
2
3
50
60
70
80
100 = End program/close socket
1000 = Close socket (start 2-second timeout)
1001 = Wait for close & abort if timeout
2000 = ARP request/response
2001 = Open Socket
Open Count Number of times socket open attempted
Close Count Number of times socket closed
Number of times socket established
Connect Count
Host IP ASCII string of remote server IP address (10 words)
t0 Timeouts Number of t0 timeouts
t1 Timeouts Number of t1 timeouts
Number of t2 timeouts
t2 Timeouts
t3 Timeouts Number of t3 timeouts
Sequence Errors Number of sequence errors
Bad Address Errors Number of bad address errors
Length Errors Number of length errors
Rx Frame Count Number of frames received on socket
Tx Frame Count Number of frames transmitted on socket
Cmd Requests Number of commands issued from command list and queue
Cmd Responses Number of responses to commands issued from command
list and queue.
Cmd Error Count Number of errors recognized when issued from command list
or queue
Requests Number of requests from command driver
Number of messages received by command driver
Responses
Errors Sent Number of errors sent by command driver (not used)
Errors Received Number of errors received by command driver
Configuration Error Configuration error word for client
Current Error Current error recognized
Last Error Last error recognized
Send sequence number
Send Number
Rec Number Received sequence number
Ack Number Last acknowledged sequence number
Queue Max Maximum number of queue (k)
Queue Threshold Queue threshold before S-Frame sent (w)
Rec Packets Number of I-frames received but not acknowledged
Number of messages in queue
Queue Now
49TPTQ-104C ♦ 48TQuantum Platform
= Ready for socket open
= Waiting for socket establish
= Obsolete (not used)
= Read and write data to socket (process data)
= Need more data for response so wait for rest of data
= Sending test frame
= Sending S-frame
= Sending StartDT act
= Sending StopDT act
47TIEC 60870-5-104 Client
ProSoft Technology, Inc.
March 4, 2013
