49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
Item
EOI Time Sync
EOI General Int
Use Time Tag
Commands
5.6.5 [IEC-104 Client/Session x > IEC-104 Client x Sector 1] section
This section defines the Data Type distribution of the module database for Client
x Sector 1.
ProSoft Technology, Inc.
March 4, 2013
Description
Range
Y or N This parameter specifies if the sector in the
controlled device will be sent a time
synchronization command after this module
receives an EOI message from the controlled unit.
Y or N This parameter specifies if the sector in the
controlled device will be sent a general
interrogation command after this module receives
an EOI message from the controlled unit.
Y or N This parameter specifies if a time tag field is to be
included with commands. This is as specified in
the IEC-870-5-104 specification and should only
be utilized if the controlled device supports these
new data types. If the parameter is set to Y, a time
tag will be added to all commands. If the
parameter is set to N, the normal IEC-870-5-101
data type messages will be utilized
Module Configuration
12TUser Manual
Page 67 of 136
