ProSoft Technology ProTalk PTQ-104C User Manual page 103

49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
Note: The values do not refresh automatically. The same keystroke ([D], [P], or
[N]) is needed to refresh the values.
IEC-104 Client Menu
Press [I] (Upper case 'i') to open the IEC-104 Client menu. Press [S] to 'show'
the first Session configuration.
To navigate in this menu, press [N] to display the next Session configuration.
Press [P] to display the previous Session configuration.
SNTP Setup Menu
Press [N] to view the SNTP setup. Refer to SNTP Support for more information
on configuring and using this function.
Version Information Menu
Press [ ] to view the module's firmware information.
V
Network Menu
Press [@] to view the module's IP address information including the subnet mask
and gateway. Press [
Exiting the Program
Caution: Some of the commands available from this menu are designed for advanced debugging
and system testing only, and can cause the module to stop communicating with the processor or
with other devices, resulting in potential data loss or other failures.
Use these commands when specifically directed to do so by ProSoft Technology Technical Support
staff. Some of these command keys are not listed on the menu, but are active nevertheless. To
prevent an unwanted command to be executed, please be careful when pressing keys.
Press [E ] to restart the module and force all drivers to be loaded. The module
SC
will use the configuration stored in the module's Flash memory to configure the
module.
ProSoft Technology, Inc.
March 4, 2013
] to 'show' the information.
S
Diagnostics and Troubleshooting
12TUser Manual
Page 103 of 136
