Diagnostics and Troubleshooting
12TUser Manual
Also, take care to distinguish capital letter [I] from lower case letter [
number [1]. Likewise for capital letter [O] and number [0].
Displaying the Current Menu
Press [?] at any time in any menu to display the current menu options.
Block Transfer Statistics
Press [ ] to display the block transfer statistics menu. Use this command to view
B
the module's status in the rack including block counts, I/O transfer settings, Hot
Standby settings, etc.
Viewing Module Configuration
Press [C] to display the current configuration and statistics for the module
including IEC 60870-5-104 protocol-specific settings.
Database View
Press [D] to view the data of the module's database. Press [S] to 'show' the IEC
60870-5-104 values coming in/out of the IEC 60870-5-104 network.
To navigate in this menu, press [N] to display the next 100 values of the data
base. Press [P] to display the previous 100 values of the data base.
Page 102 of 136
49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
] and
