Reference
12TUser Manual
Test procedure
(Station-specific parameter, mark "X" if function is only used in the standard
direction, "R" if only used in the reverse direction, and "B" if used in both
directions)
B Test procedure
File transfer
(Station-specific parameter, mark "X" if function is used)
File transfer in monitor direction

Transparent file

Transmission of disturbance data of protection equipment

Transmission of sequence of events

Transmission of sequence of recorded analogue values

File transfer in control direction

Transparent file
Background scan
(Station-specific parameter, mark "X" if function is only used in the standard
direction, "R" if only used in the reverse direction, and "B" if used in both
directions)

Background scan
Definition of time outs
Default Value
Parameter
30 seconds
t
0
15 seconds
t
1
10 seconds
t
2
20 seconds
t
3
Maximum range of values for configurable time-outs: accuracy 1 second.
Maximum number of outstanding I format APDUs k and latest acknowledge
APDUs (w)
Default Value
Parameter
6 APDUs
k
4 APDUs
w
Maximum range of values k: 1 to 32767 (2
Maximum range of values w: 1 to 32767 (2
(Recommendation: w should not exceed two-thirds of k).
Page 128 of 136
Remarks
Time-out of connection establishment
Time-out of send or test APDUs
Time-out for acknowledges in case of no data
messages (t < t )
2 1
Time-out for sending test frames in case of a
long idle time
Remarks
Maximum number of message to hold in queue
Threshold value when to send ack
15
-1) APDUs, accuracy 1 APDU
15
-1) APDUs, accuracy 1 APDU
49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
Range
1 to 1000 seconds
1 to 255 seconds
1 to 255 seconds
1 to 300 seconds
Range
1 to 12
1 to 8
ProSoft Technology, Inc.
March 4, 2013
