49TPTQ-104C ♦ 48TQuantum Platform
47TIEC 60870-5-104 Client
8

Diagnostics and Troubleshooting

In This Chapter

LED Indicators ....................................................................................... 94

Diagnostics Menu .................................................................................. 95
The module provides information on diagnostics and troubleshooting in the
following forms:

LED status indicators on the front of the module provide general information
on the module's status.

Status Data can be viewed through the Configuration/Debug port using
ProSoft Configuration Builider (PCB) software.

Status data values can be transferred from the module to processor controller
tags and can be monitored manually or by customer-created logic.
ProSoft Technology, Inc.
March 4, 2013
Diagnostics and Troubleshooting
12TUser Manual
Page 93 of 136
