Module Configuration
12TUser Manual
Printing a configuration file
1 Select the module icon, and then click the right mouse button to open a
shortcut menu.
2 On the shortcut menu, choose V
the View Configuration window.
3 On the View Configuration window, open the F
choose P
RINT
4 On the Print dialog box, choose the printer to use from the dropdown list,
select printing options, and then click OK.
5.2

Backplane Data Transfer

On every scan, the PTQ-104C transfers all Read and Write database values
between the module and the processor.
The module will hold the processor scan for a certain period of time to complete
the transfer. Therefore, the larger the read and write areas, the longer the
processor scan time will be.
The [Module] section of PCB defines the starting registers for read and write
operations. It also defines the length of each data area.
Page 42 of 136
IEW
. This action opens the Print dialog box.
49TPTQ-104C ♦ 48TQuantum Platform
C . This action opens
ONFIGURATION
menu, and
ILE
47TIEC 60870-5-104 Client
