Data Type Description
Word address, Normalized measured
110
value
Word address, Scaled measured value
111
Float (double-word), Short float value
112
*Word address, Activation command
113
5.8

[Ethernet Configuration] section

See page 19 for more information.
5.9

To Create Optional Comment Entries

1 Click the plus sign to the left of the
Comments.
ProSoft Technology, Inc.
March 4, 2013
Qualifier Parameter
The following applies to Type 110, 111,
112:
Type of parameter:
0=Not used
1=Threshold value
2=Smoothing factor (filter time constant)
3=Low limit for transmission of measured
values
4=High limit for transmission of
measured values
5 to 31 = Reserved by standard
32 to 63 = Reserved for special use
(private range)
Local parameter change:
0=No change
64=Change
Parameter in operation:
0=Operation
128=Not in operation
Parameter Qualifier:
0=Not used
1=Act/Deact of previously loaded
parameters (point index = 0)
2=Act/Deact of the parameter of the point
index specified
3=Act/Deact of persistent cyclic or
periodic transmission of the addressed
object
4 to 127 = Reserved by standard
128 to 255 = Reserved for special use
(private range)
Activation Qualifier:
0=Deactivate
256=Activate
icon to expand the module
Module Configuration
